Features

• Eco-friendly, chemical-free UV disinfection system
• Italian made with premium components for superior quality and performance
• IP54 rated digital control panel with monitor display and lamp life counter
• Acoustic alarm alerts for timely lamp replacement
• Lockable, weather-resistant cover for added protection
• Reversible mounting for flexible installation and optimal pipe routing
• Pre-plumbed configuration ensures quick and tidy installation
• High maximum working pressure of 8.3 bar

Specifications

• Brand: Atlas Filtri
• Product Type: UV Units
• Flow Rate: 54 L/min @ 40mJ/cm²
• Material: Reinforced Polypropylene Filter Housings
• UV Reactor Material: 304 Stainless Steel
• Nominal Micron Rating: 1
• Filter: 10" Big
• Inlet/Outlet: 1" BSPF Inlet / 1" BSPM Outlet
• Max Pressure: 8.3 bar
• Min Temperature: 4°C
• Max Temperature: 45°C
• Power Consumption: 61 Watts
• Power Supply: AC 110–240V, 50/60Hz
• Power Cable Length: 2 m
• UV Dose: 30–40 mJ/cm²
• Protection Class: IP54
• Dimensions (H x W x D): 790 x 722 x 205 mm
• Application: Whole Supply
• Shipping Weight: 20 kg

Includes

• Big F Pro 156 UV unit with integrated IP54 control panel
• TS 20 Micron Pleated 10” Big Filter Cartridge
• Carbon Block 5 Micron 10” Big Filter Cartridge
• Lockable weather-resistant mounting cover
• Pre-plumbed bracket with single inlet/outlet connection
• Digital display with lamp life counter and audible alarm
