Features

• Moving the handle moves the push-pull rod for quick clamping action.
• Provides automatic and infinitely variable adjustment of the clamping height up to 13 mm while the clamping force remains unchanged, without needing manual adjustment of the pressure screws.
• Offers adjustable clamping force up to 2,500 N based on the adjusting screw in the joint.
• Constructed from sturdy, tempered metal sheets for a long service life.
• Has a base plate hole pattern suitable for both millimetres and inches.
• Fitted with a high-quality, oil resistant two-component plastic handle with slip protection (STC-IHH15).

Specifications

• Reference No.: STC-IHH25
• Opening: 35 mm
• Automatic Adjustment: 13 mm
• Clamping Pressure: 2500 N approx.
• Weight: 0.20 kg approx.
