Features

• Advanced Multistage Pressure System: Designed for water supply, boosting, and irrigation in domestic, agricultural, and gardening applications.
• NXT Intelligent 2-Mode Controller: Provides smart pressure management for optimized efficiency and performance.
• Powerful Water Flow: Delivers a maximum flow rate of 120 liters per minute, supporting up to 12 taps.
• Strong Water Pressure: Operates at 5.8 Bar with a maximum head of 59 meters for consistent water distribution.
• Energy-Efficient Motor: 1.0 kW (1.36 hp) electric motor runs on 240V with a 6.5A draw.
• Drinking Water Approved: Certified safe for clean water applications.
• Durable and Reliable: Engineered for long-lasting operation with high-quality materials.
• Easy Installation: Features a 1" BSPF inlet and 1" BSPM outlet for secure and hassle-free connections.

Specifications

• Brand: DAB Pumps
• Product Type: Pressure System
• Suitable For: Clean Water
• Maximum Pressure: 5.8 Bar
• Approval: Drinking Water Approved
• Amps: 6.5 A
• Flow Capacity: 100 - 199 L/min
• Maximum Flow Rate: 120 L/min
• Head Range: 40 - 59 meters
• Maximum Head: 59 meters
• Motor Power: 1.0 kW (1.36 hp)
• Pressure: 578 kPa
• Power Source: Electric
• Voltage: 240V
• Number of Taps Supported: 12
• Inlet Connection: 1" BSPF
• Outlet Connection: 1" BSPM
• Power Consumption: 1000W

Warranty

• 2-Year DAB Pumps Warranty: Covers parts and labor for peace of mind.
