Features

• Japanese technology with dual braking system for safe and reliable operation
• Half-press button operation allows the hoist to run at half speed for precision control
• Compact and lightweight design for easier handling
• Weight overload limiter ensures operator safety
• Thermal overload motor protection for extended motor life
• Single-phase 240V motor for convenient power supply compatibility
• Upper and lower limit switches prevent chain runout
• Customizable chain length available upon request
• Tested and certified to AS 1418.2 standards
• Supplied with test certificate and user manual

Specifications

• Rated Capacity: 1 Tonne
• Standard Lift: 3m
• Running Test Load: 12.5kN
• Motor: 1200W, 240V, Single Phase
• Number of Chain Drops: 1
• Chain Type: Grade 80, 7.1mm
• Lift Speed: 6/2 m/min
• Net Weight: 60kg
• Extra Weight Per Metre of Additional Lift: 1.1kg
