Features

• Tank Size (l):
• 800
• Pump Size (l/min):
• 415
• Max Pressure:
• 80psi
• Product Weight (kg):
• Height / Width / Length (mm):
• 1090 / 940 / 1800
• Tank :
• A 800L UV Stabilised Impact resistant Polytuff tank with TWIN Internal baffle to reduce surge when travelling. A 255mm screw type lid and strainer. Drain Bung for easy empty and cleaning. Tie down points moulded into the top of the tank for attaching to a tray
• Engine :
• A 4 stroke, 5.5 Hp GX160 Honda 163 (cc) with manual recoil rope start. Low oil protection, Oil used SAE 10W 30 (600ml). Twin stage - foam prefilter with paper final element
• Fuel Tank :
• Capacity 3.1 Litres (Unleaded) with approximate fuel consumption @ full load 1.7L
• Pump Specifications :
• Viton equipped internal seal, O-rings & gaskets. Fitted for improved chemical resistance. Important: Please seek specialist advice from chemical supplier if pumping chemicals. Use of aggressive chemicals may void warranty
• Pump Performance :
• Maximum output 415 (L/min), Max Pressure 80 (PSI). Direct coupled single centrifugal impeller. Inlet 1 x 1.5". Outlet 2 x 1.5" (Spare). 2 x 1" used for the Hose reel & 3-way valve to deliver water back to the tank
• Hose Reel :
• Manual wind, Heavy duty powder coated steel. 30m " ID delivery hose. Adjustable nozzle, approximate flow rate 20L/min. At full load, distance of water directed from the adjustable nozzle can be up to approximately 20mtrs
• Tank Run Time :
• Approximately 40 mins (when full of water)
• Dam Fill Kit (factory Fitted) :
• 6m suction hose and filter with camlocks for easy use and storage. 1 x 3-way valve fitted to the pump that changes the position of suction from the tank to using Dam fill kit. 1 x Ball valve fitted to deliver water from the pump to the tank
• Other :
• Engine has been filled with oil, but not fuel. Do not run dry
