Features

• Poly V-belt and motor driving system enhances service life
• Soft start minimizes recoil force during motor startup
• Electronic constant speed control for consistent performance
• Positive mitre stops for quick and easy adjustments

Specifications

• Input Power: 1,450W
• No Load Speed: 3,800 min^-1
• Blade Diameter: 255mm
• Blade Bore: 25.4mm
• Weight: 19.5kg
• Dimensions: 525 x 1050 x 615mm

Cutting Capacity

• 0° (Right angle): 88mm x 312mm, 91mm x 300mm
• Mitre right/left 45°: 88mm x 218mm, 91mm x 200mm
• Mitre right 57°: 88mm x 165mm, 91mm x 150mm
• Bevel left 45°: 55mm x 305mm, 60mm x 290mm
• Bevel right 45°: 30mm x 305mm, 35mm x 290mm
• Mitre right/left 45° + Bevel left 45°: 55mm x 218mm, 60mm x 200mm
• Mitre right/left 45° + Bevel right 45°: 30mm x 218mm, 35mm x 200mm

Mitre and Bevel Angles

• Mitre Angle Range: 0° - 45° left, 0° - 57° right
• Bevel Angle Range: 0° - 45° left and right
• Positive Mitre Stops: 0°, 15°, 22.5°, 31.6°, 45°

Includes

• Blade
• Dust bag
• Vice assembly
• Wrench

Warranty

• 3 Years Standard Warranty, extendable to 6 years upon online registration
