Features

• Compact slide system with fixed rails for zero clearance, ideal for narrow job sites
• LED Shadow light for precise alignment of blade to cut line, enhancing visibility
• Freely adjustable blade angle with a one-touch mitre lock for quick adjustments
• Durable metal adjustable scale provides accuracy and durability
• Front access to bevel and mitre locks for easy adjustments in confined spaces

Applications

• Perfect for cutting various wood types, plywood, and decoration panels
• Suitable for soft fiberboards, hard boards, and aluminum sashes

Specifications

• Power Supply: AC 240V
• Power Input: 1,520W
• Blade Diameter: 305mm (12")
• Mount Hole Diameter: 25.4mm (1")
• Bevel Function: Dual Bevel
• Mitre Angle: 45° left, 57° right
• Cross Cut (0°): 107 x 312mm (H x W)
• Bevel Left 45°: 70 x 312mm (H x W)
• Bevel Right 45°: 45 x 312mm (H x W)
• Mitre Left 45° + Bevel Left 45°: 70 x 220mm
• Mitre Left 31° + Bevel Right 45°: 45 x 265mm
• Mitre Right 45° + Bevel Right 45°: 45 x 220mm
• Mitre Right 31° + Bevel Left 45°: 70 x 265mm
• Maximum Mitre Angle: 107 x 170mm
• No Load Speed: 4,000/min
• Positive Stops: Yes
• LED Lighting System: Yes
• Dimensions (L x W x H): 873 x 916 x 724mm
• Weight: 25.5kg

Includes

• Dust bag
• Vise assembly
• 8mm hex bar wrench
• Holder
• TCT saw blade (305mm)
• Sub table assembly

Warranty

• 3 Years Standard Warranty, extendable to 6 years upon online registration
