Features

• Produces burr-free holes up to 100mm diameter and 110mm depth
• 1500W motor with 4-speed mechanical gearbox delivers outstanding torque through low-speed gear reduction
• No. 3 Morse Taper spindle bore compatible with taper shank drills, M30 capacity tapping heads, and taper shank reamers
• Includes side-mounted coolant system for efficient cooling during operation
• Supplied with arbor for ¾" shank Holemaker cutters up to 75mm diameter and 75mm depth
• Optional arbor available for 1-1/4" shank cutters up to 110mm diameter and 110mm depth
• 1100ml pressure feed coolant bottle available for large diameter and deep hole drilling
• Italian-made motor paired with heavy-duty 4-speed gearbox for reliable performance
• Rigid design helps prolong machine and tooling life
• Magnetic Field Shape Control (MFSC) ensures maximum holding power on thin materials
• Magnetic Power Adhesion Control (MPAC) monitors adhesive force for operator safety
• Semi-automatic gib adjustment for fast and accurate slide backlash settings
• Lightweight for its capacity, designed for easier handling

Specifications

• Maximum Hole Diameter: 100mm
• Maximum Hole Depth: 110mm
• Twist Drill Capacity: 31.75mm
• Spindle Taper: MT3
• Motor Power: 1500W, 240V
• Input Power: 1650W
• Speed Range: 100 / 175 / 275 / 500 rpm (4-speed gearbox)
• Weight: 24kg
• Magnetic Dead Lift: 18,000 N on 25mm steel plate
• Stroke: 225mm
• Height Range: 531mm (min) / 756mm (max)
