Features

• Produces clean, burr-free holes up to 80mm diameter and 110mm depth
• 1500W motor with 2-speed mechanical gearbox delivers exceptional torque via gear reduction at low speeds
• No. 3 Morse Taper spindle bore compatible with taper shank drills, M30 capacity tapping heads, and taper shank reamers
• Includes side-mounted coolant system for efficient cutting performance
• Supplied with arbor for ¾" shank Holemaker cutters up to 75mm diameter and 75mm depth
• Optional arbor available for 1-1/4" shank cutters up to 80mm diameter and 110mm depth
• Lightweight for its capacity, weighing only 18kg
• Rigid casting design withstands firm downward drilling force, extending machine and tooling life
• Italian-made motor paired with a heavy-duty 2-speed gearbox for reliable performance
• Semi-automatic gib adjustment ensures quick, precise, and repeatable slide backlash settings
• Magnetic Field Shape Control (MFSC) ensures maximum holding power on thin materials
• Magnetic Power Adhesion Control (MPAC) detects and safeguards against insufficient adhesive force

Specifications

• Maximum Hole Diameter: 80mm
• Maximum Hole Depth: 110mm
• Twist Drill Capacity: 25mm
• Spindle Taper: MT3
• Motor Power: 1500W, 240V
• Input Power: 1600W
• Speed: 160/390 rpm (2-speed heavy-duty gearbox)
• Weight: 18kg
• Magnetic Dead Lift: 11,000 N on 25mm steel plate
• Stroke: 190mm
• Height Range: 476mm (min) / 666mm (max)
