Features

• Quality European manufacture.
• Double action hydraulic punches.
• Wide range of hole diameters up to 27mm.
• Heavy duty fabricated steel construction.
• Intelligent control system with inching and automatic load detection.
• Mode indicator light.
• Protection against accidental start-up.
• Easy to handle both in and out of working positions.
• All connecting ports located at the rear of machine.
• Wide range of special-shaped punches and dies available on request.
• Can be used with Double Action Hydraulic Power Pack HPP 700

Specifications

• Max. Plate Thickness: 13mm
• Max. Throat Depth: 60mm
• Max. Hole: Ø 27mm
• Max. Oval Hole: 25 x 18mm
• Punching Time: 5 seconds
• Punching Power: 35 ton
• Working Pressure: 10152 PSI
• Weight: 20kg
