Features

• Silent Series piston compressor design delivers the quiet operation of a screw compressor with the cost efficiency of a piston unit
• Ideal for workplaces where compressors run extensively and are located close to the work area
• Low-speed pump operation paired with a sound-proof cabinet, compact design, and user-friendly control panel for reduced noise and improved efficiency
• Triple cast-iron cylinder, oil-lubricated pump with aluminium head
• High-efficiency induction motor for dependable performance
• Soft start valve for enhanced electric motor protection
• Thermal overload protection with manual reset
• Full brass non-return valve
• Certified safety valve
• Reliable Condor pressure switch

Specifications

• Motor: 10 HP – Three phase, 415 V
• Tank capacity: 270 L
• Maximum pressure: 147 PSI (10 bar)
• Pump displacement: 1269 L/min (44.8 CFM)
• Free air delivery: 960 L/min (33.9 CFM)
• Pump RPM: 950
• Compressor dimensions: 135 cm (L) × 75 cm (W) × 180 cm (H)
