Features

• Swivel head design allows mitre cuts from 0° to 60°, providing excellent versatility for a wide range of angled cutting applications.
• Dual mode operation offers maximum flexibility:
  • Trigger switch with manual down feed for small, quick cuts.
  • Control panel with fully adjustable hydraulic down feed and automatic shut-off at the end of the cut for precise and efficient cutting of larger materials.
• Integrated recirculating coolant system keeps the blade cool, enhances cut quality, and extends blade life.
• Brass chip brush helps prevent blade breakage by keeping chips clear during operation.
• Adjustable material stop enables consistent, repeatable cuts, making it ideal for production and repetitive tasks.
• Equipped with a safety emergency stop switch for immediate shutdown, ensuring operator safety.
• Includes a 12-month warranty for peace of mind and reliable support.
• Supplied complete with stand and blade, ready for immediate use out of the box.
• Optional blade tension gauge available for optimal blade maintenance and accuracy.
• High-quality construction, proudly made in Taiwan for dependable, long-term performance.

Specifications

• Motor: 1.5 hp, single-phase (240V)
• Blade speed: Single speed, 72 m/min
• Blade size: 27 mm x 0.9 mm x 2460 mm
• Bed height: 840 mm
• Weight: 216 kg

Cutting Capacity

• 90° cutting capacity — Round: 220 mm; Square: 215 mm; Rectangle: 260 x 110 mm
• 45° right cutting capacity — Round: 150 mm; Square: 145 mm; Rectangle: 155 x 110 mm
• 60° right cutting capacity — Round: 90 mm; Square: 85 mm; Rectangle: 95 x 80 mm
