Features

• Specialised welding tractor designed for precise and efficient welding of steel profiles used as reinforcement elements, such as flat bars, angle profiles (L), T-bars, bulb flats, I-beams, H-beams and channels (C-profiles).
• Allows operation with two torches simultaneously in continuous or intermittent welding mode.
• Programming function allows the desired welding path to be set by specifying parameters such as weld length, skip length and crater filling at the beginning and end of the welds.
• 18V DC Lithium-Ion High Density battery (LiHD) ensures extended power availability, even for a whole shift, using the same CAS battery as other cordless machines in the range.
• Designed for travelling on steel profiles such as flats, angles, I-beams, T-beams, bulb flats and irregularly shaped workpieces with a radius down to 160mm.
• Dual-sided operation with two torches in continuous or intermittent welding mode.
• Simple and ergonomic programming of weld patterns and stitch welding parameters.
• Multifunctional LED display shows travel speed, units, welding settings and diagnostic messages.
• 18V DC power allows safe use in harsh environments like shipyards that are often wet, metallic and confined.
• LiHD battery, supported by intelligent battery management, ensures maximum power availability for an extended period.
• Closed-loop speed control system stabilises travel speed, enabling uniform heat input for consistently high-quality welds.
• Backed by a 3 year warranty.

Specifications

• Voltage: 18V DC, 4.0Ah
• Power: 18W
• Welding Position, Horizontal (EN ISO 6947 and AWS/ASME): PA/1F/1G, PB/2F
• Torch Type: MIG/MAG
• Torch Diameter: 16-22mm (5/8-55/64 inch), up to 35mm (1.38 inch) optional
• Horizontal Pulling Force: 150N
• Cross Slide Adjustment Range: 0-35mm (0-1.38 inch) up/down, left/right
• Horizontal Speed: 5-130cm/min
• Weight (without battery): 7kg
• Brand: ITM
• Model: WA-MANTIS
