ITM PRO10 273MM PIPE BEVELLER PNEUMATIC WA-PRO10PBA

Features

• The ITM PRO 10 PB is a heavy-duty, European-made I.D. mounted portable pipe bevelling machine designed for large capacity pipe preparation, yet lightweight enough (31.5 kg) for efficient single-operator use.
• Equipped with self-centering expandable mandrels for fast and precise alignment inside the pipe, ensuring accurate and consistent bevels.
• Capable of simultaneously performing up to three operations: internal bevel, external bevel, J-groove bevel, face off, I.D. chamfer, and counterbore, streamlining the preparation process.
• While it can be operated with a single cutting insert, optimal performance is achieved using three cutting inserts at once for faster, smoother machining.
• Available in two power options: the PRO10PBE with a high-torque electric motor and the PRO10PBA with a pneumatic motor, to suit different work environments and operator preferences.

Specifications

• Motor type: Pneumatic motor, 1.5 kW
• Power requirements: 1,750 L/min at 630 kPa
• Spindle speed: 20 rpm for controlled, heavy-duty cutting
• Pipe machining range with standard mandrel: 84 mm I.D. to 269 mm I.D.
• Weight (with standard mandrel): 32.0 kg

Includes

• PRO 10 PB bevelling machine
• Electric or pneumatic motor (depending on model)
• Mandrel for 84 mm I.D. to 269 mm I.D. pipes
• Jaw block set numbers 1 to 6
• Toolbox with tools
• Coolant bottle
