Features

• This is a self-leveling cross-line laser level that projects both horizontal and vertical lines for quick leveling and alignment work.

Specifications

• Brand: Leica Geosystems
• Model: 864413
• EAN/UPC: 7640110697528
• Related Kit: also listed as part of the L2 starter kit, Art. No. 848435
• Range: up to 25 m depending on lighting conditions
• Range With Laser Receiver: up to 80 m depending on lighting conditions
• Levelling Accuracy: +/- 0.2 mm/m
• Self-Levelling Range: +/- 4 degrees
• Self-Levelling Time: less than 3 s
• Number Of Laser Lines: 2
• Beam Direction: vertical, horizontal
• Laser Line Width At 5m: less than 2 mm
• Laser Type: 635 nm / class 2 (red)
• Battery Type: Li-Ion rechargeable (or 3 x AA 1.5 V)
• Operating Time: up to 44 h (Li-Ion), depending on laser mode
• Temperature Range, Storage: -25 to 70 deg C (-13 to 158 deg F)
• Temperature Range, Operation: -10 to 50 deg C (14 to 122 deg F)
• Protection Class: IP 54
• Dimensions: 110 x 60 x 100 mm
• Weight With Batteries: 530 g
• Tripod Thread (Lino): 1/4"
• Tripod Thread (Adapter): 1/4" + 5/8"
