Features

• Uses new green diode technology that provides outstanding visibility for indoor applications.
• Suitable for both interior and exterior levelling, aligning, and squaring applications.
• Works conveniently with offsets thanks to the digital read-out on the Rod Eye 120G receiver, which measures the offset from the Rugby 640G beam position, adding convenience and saving time.
• Features a Scan90 function that makes layout easier by quickly moving the beam 90 degrees to the left or right side.
• Includes a Plumb Down function that provides automatic and accurate plumb-down direction for alignment over a reference point.
• Includes a Sleep Mode that saves battery power by putting the Leica Rugby into sleep mode without disturbing the current setup.
• Powered by alkaline batteries.
• Comes with an RC400 remote control included in the package.

Specifications

• Functionality: Self-Levelling Horizontal, Vertical, 90 Degrees And Manual Slope In Dual Axis
• Range (Diameter): 400 m
• Self-Levelling Accuracy (Defined At 25 deg C): +/- 2.2 mm @ 30 m
• Self-Levelling Range: +/- 5 degrees
• H.I. Elevation Alert: Yes
• Rotation Speeds: 0, 2, 5, 10 rps
• Scanning Modes: 10, 45, 90 degrees
• Scan90: Yes
• Plumb Up: Yes
• Plumb Down: Yes
• Sleep Mode: Yes
• Laser Diode Type / Class: 520 nm / Class 2
• Dimensions (H x W x D): 212 x 239 x 192 mm
• Batteries (Alkaline): Four D-Cells
• Battery Life (Alkaline): 60 Hours @ 20 deg C
• Weight With Batteries: 2.6 kg
• Protection Class (Splash Water / Dust Proof): IP67
• Operating Temperature Range: -20 to +50 deg C
• Remote Range (Radius): 100 m
• Brand: Leica Geosystems
• Model: LG6011488
