Leica Rugby CLAx 700 Dial-In Dual Grade +/-15% Laser Level LG6018543CLC
Was $5,500.00
Save $1,000.00 (18%)
Delivers fast, precise, and flexible performance across a range of grading and levelling tasks. Dial in a grade of up to 15% for both horizontal and vertical tasks, suiting more demanding grading applications. Offers digital dual-grade capability, allowing two grades to be set and managed digitally. Operates in both the horizontal plane and the vertical (laydown) plane. Self-levelling within a range of +/-6 degrees, allowing the unit to automatically correct for minor setup errors. Includes a power-safe mode that runs the head at 7 RPS to conserve battery life when full rotation speed is not required. Head stall alert notifies the operator if the rotating head unexpectedly stops turning. Temperature stability control, selectable at 2 deg C, 5 deg C, or off, helps compensate for temperature-related drift that can affect accuracy. HI (height index) alert warns the user if the instrument is bumped or knocked out of level after it has been set up. Beam masking lets sections of the laser beam be blocked off where they are not needed. Beam scanning modes at 10, 45, and 90 degrees improve beam visibility for specific tasks. Slope catch/lock function holds a set grade automatically once it has been dialled in. Plumb-up beam provides a vertical reference point for alignment tasks. Supports single-grade semi-automatic levelling with a dial-in grade of up to +/-8%, single-grade fully-automatic levelling with a dial-in grade of up to +/-15%, and dual-grade fully-automatic levelling with a dial-in grade of up to +/-15%, covering a wide range of grading methods. Model: CLAx700. Self-Levelling Accuracy: +/-1.5mm at 30m. Head Speed: 0, 2, 5, 10, 15 RPS (0, 120, 300, 600, 900 rpm). Battery Operating Time: 50 hours. Brand: Leica Geosystems. Leica Rugby CLaX 700 Laser Level. CLC Combo+ Laser Remote / Receiver. Li-Ion Battery. Battery Charger. User manual. Carry Case.
Read full descriptionIn stock
Apple Pay, Google Pay, Link and PayPal, no account needed
Delivery to your door
Features
- Delivers fast, precise, and flexible performance across a range of grading and levelling tasks.
- Dial in a grade of up to 15% for both horizontal and vertical tasks, suiting more demanding grading applications.
- Offers digital dual-grade capability, allowing two grades to be set and managed digitally.
- Operates in both the horizontal plane and the vertical (laydown) plane.
- Self-levelling within a range of +/-6 degrees, allowing the unit to automatically correct for minor setup errors.
- Includes a power-safe mode that runs the head at 7 RPS to conserve battery life when full rotation speed is not required.
- Head stall alert notifies the operator if the rotating head unexpectedly stops turning.
- Temperature stability control, selectable at 2 deg C, 5 deg C, or off, helps compensate for temperature-related drift that can affect accuracy.
- HI (height index) alert warns the user if the instrument is bumped or knocked out of level after it has been set up.
- Beam masking lets sections of the laser beam be blocked off where they are not needed.
- Beam scanning modes at 10, 45, and 90 degrees improve beam visibility for specific tasks.
- Slope catch/lock function holds a set grade automatically once it has been dialled in.
- Plumb-up beam provides a vertical reference point for alignment tasks.
- Supports single-grade semi-automatic levelling with a dial-in grade of up to +/-8%, single-grade fully-automatic levelling with a dial-in grade of up to +/-15%, and dual-grade fully-automatic levelling with a dial-in grade of up to +/-15%, covering a wide range of grading methods.
Specifications
- Model: CLAx700
- Self-Levelling Accuracy: +/-1.5mm at 30m
- Head Speed: 0, 2, 5, 10, 15 RPS (0, 120, 300, 600, 900 rpm)
- Battery Operating Time: 50 hours
- Brand: Leica Geosystems
Includes
- Leica Rugby CLaX 700 Laser Level
- CLC Combo+ Laser Remote / Receiver
- Li-Ion Battery
- Battery Charger
- User manual
- Carry Case
- MPN
- LG6018543CLC
- Manufacturer
- Leica
