Features

• Designed in Australia; represents the pinnacle of deadbolt security for residential and architectural applications
• Multi-mode slimline deadbolt offering safety, security and convenience in one unit
• Incorporates Lockwood's patented LockAlert® status indicator, displaying the current lockset mode at a glance across three modes: Secure Mode (locked from both sides), Safety Mode (locked from outside, free to exit from inside), and Passage Mode (free entry and exit from both sides)
• DualSelect® technology: turn the key for Safety Mode, turn further to engage Secure Mode
• SafetyRelease™ automatically unlocks the internal knob upon entry, minimising the risk of being locked inside
• Kinetic Defence® bump and pick resistant cylinder
• High-security cut-resistant stainless steel bolt
• Counterbalance bolt proportionally distributes load between the door and door frame for improved structural integrity
• Box strike with concealed crossgrain door frame strengthening screw
• Retrofittable — replaces existing deadbolts; fits standard 54mm hole with 60–70mm adjustable backset
• Simple to install
• Available in round or square designs
• Can be keyed alike to other Lockwood door locks; compatible with master key and restricted keying systems for controlled access
• Successfully tested for anti-corrosion in accordance with AS2332.3.1:2001 neutral salt spray test; available in stainless steel for increased corrosion resistance
• Conforms to the security and durability requirements of Australian Standard AS4145.2-2008 | SL8D8C6K5

Specifications

• Backset: 60–70mm adjustable stainless steel bolt
• Door thickness: 32–48mm (32–36mm doors require included spacer ring)
• Cylinder: 5 pin tumbler mechanism with brass cylinder and brass barrel
• Case material: High purity zinc alloy
• Stainless steel version features 304 grade satin stainless steel rose, turn knob and trim
• Key combinations: 78,000
• Key blank: KB2015P
• Available finishes: Chrome Plate (CP), Satin Chrome Pearl (SP), Satin Chrome Brushed (LSC), Everbrass (EVB), Satin Stainless Steel (SSS) — round version only
• Durability: Conforms to Level D8 of Australian Lock Standard AS4145.2-2008

Includes

• 2 keys per lock
• Spacer ring for doors 32–36mm thick
