Features

• Compact mobile table saw with impressive cutting performance and high comfort for working
• Anti-twist tubular frame construction for highest demands on the building site and during installations
• Cables and all add-on components for transport can be stored on the casing
• Powerful motor with electronic overload protection
• Motor brake for quick stop of the saw blade in 3 seconds
• Restart protection: prevents unintentional start-up after power supply interruption
• Soft start for long service life of motor and drive
• Precisely adjustable rip fence with double clamping and quick fastening
• Precise saw blade inclination via gear guide
• Automatic resetting to 0 - 45 degrees after undercuts
• Easy saw blade change with spindle lock
• Splitting wedge can be lowered without tools for hidden cuts and transport
• Precise, extendable table width extension for extra large working surfaces

Specifications

• Dimensions: 669 x 748 x 334 mm // 26.343 x 29.437 x 13.156 "
• Working height: 334 mm // 13.15 "
• Cutting height: 0 - 80 mm // 0 - 3.15 "
• Maximum cutting height: 90/45 degrees 80 / 48 mm // 3.15 / 1.87 "
• Maximum cutting width at rip fence: 520 mm / 20.46 "
• Maximum material width at mitre fence: 195 mm / 7.68 "
• No-load speed: 4200 rpm
• Cutting speed: 56 m/s / 184 ft/s
• Saw blade: 254 x 30 mm // 10 x 1.181 "
• Saw blade swivel range: -1.5 - 46.5 degrees
• Rated input power S1 100%: 1500 W
• Weight: 24.4 kg / 54 lbs
• Cable length: 2.3 m / 90.565 "
• Noise emission
• Sound pressure level 92 dB(A)
• Sound power level (LwA) 105 dB(A)
• Uncertainty of measurement K 3 dB(A)

Includes

• Carbide saw blade with alternately bevel-ground tips (40 teeth)
• Mitre Fence
• Table Length Extension
• Table width extension (right)
• Push stick
• TSU Stand
• Rip Fence
• AU61025400 - Saw
• 629003000 - Stand
