Features

• 20-tonne lifting capacity, suited to heavy machinery, trucks and large vehicles
• Adjustable height range of 260 mm to 510 mm for versatile lifting tasks
• Extension screw adds up to 80 mm of fine height adjustment for precise positioning
• Pneumatic switch operation via air compressor connection removes manual pumping effort
• Double-spring design allows quick, stable resetting between lifts for faster workflow
• High-quality welding and seals guard against oil leakage for reliable long-term use
• Built-in safety valve prevents overloading and keeps operation within rated capacity
• Corrosion-resistant coating and reinforced hydraulic cylinder and piston rod for durability
• Compact design with built-in carry handle for easy transport between job sites
• Best stored in a clean, dry area away from heat and corrosive substances
• Periodic lubrication with hydraulic fluid maintains smooth operation and extends service life

Specifications

• Model: LHJ20
• Capacity: 20,000 kg (20 tonnes)
• Min. Height: 260 mm
• Max. Height: 510 mm
• Adjustable Height (Extension Screw): 80 mm
• Lifting Height: 170 mm
• Package Dimensions (CTN): 28 x 21 x 30 cm
• Weight: 16 kg

Includes

• Air hose
• 20 PM connector
