Features

• 54V brushless plunge saw delivers cordless performance with corded precision
• Wireless Tool Control enables automatic activation of compatible dust extractors
• Parallel plunge design allows smooth and consistent hand positioning while cutting
• 42-tooth blade provides clean, accurate cuts with minimal breakout in laminates
• Rail adjustment ensures precise alignment with guide rails
• Anti-kickback feature prevents the saw from moving backwards or lifting during plunge cuts
• Variable speed control adapts to different materials
• Enclosed guard offers up to 90% dust extraction efficiency
• 55mm depth of cut handles common door trimming and sizing tasks

Specifications

• Voltage: 54V
• No Load Speed: 2500 – 4200rpm
• Blade Diameter: 165mm
• Blade Bore: 20mm
• Bevel Capacity: 47°
• Max Depth of Cut at 90°: 59mm
• Max Depth of Cut at 90° with Guide Rails: 55mm
• Max Depth of Cut at 45°: 44mm
• Max Depth of Cut at 45° with Guide Rails: 40mm
• Dimensions (L x H): 303mm x 265mm
• Weight: 4.7kg
• Vibration: 1.1m/s² (K = 1.5m/s²)
• Sound Pressure: 82.2dB(A) (Uncertainty: 2.9dB)
• Sound Power: 93.2dB(A) (Uncertainty: 2.9dB)
• Warranty: 3 Years Covered by DeWALT Australia

Includes

• 1 x DeWalt DCS520NT-XJ 54V XR FLEXVOLT Brushless Plunge Saw (Tool Only)
• 1 x DeWalt DWS5022-XJ 1.5m Guide Rail
• 2 x DeWalt DCB546-XE 18V/54V 6.0Ah XR FLEXVOLT Batteries
• 1 x DeWalt DCB116-XE 12V–54V Battery Charger
• 1 x DeWalt TStak VI Deep Tool Storage Box (DWST1-71195)

Features

• Guide rail supports 2-sided operation with replaceable rubber, high-friction, and low-friction strips
• XR FLEXVOLT batteries power both 18V XR and 54V FLEXVOLT tools for ultimate versatility
• Charger supports all 12V, 18V, and 54V XR/FLEXVOLT batteries with 6A output
• Stage 1 and 2 LED indicators show charging progress
• TStak box offers 23L storage, removable tray, and heavy-duty construction with padlock eyes

Specifications

• Guide Rail: 1500mm (L) x 185mm (W), Weight: 2.6kg
• Batteries: 6.0Ah, Voltage: 18V / 54V, Weight: 0.9kg
• Charger: Voltage: 12V–54V, Charging Current: 6.0A
• Charge Times:
  • DCB183 (2.0Ah): 30 mins
  • DCB182 (4.0Ah): 60 mins
  • DCB184 (5.0Ah): 75 mins
  • DCB546 (6.0Ah): 80 mins
  • DCB547 (9.0Ah): 110 mins
  • DCB548 (12.0Ah): 150 mins
• TStak VI Box: 440mm (L) x 332mm (W) x 301mm (H), Weight: 3kg
