Features

• Deep Cut Technology delivers an impressive 47 mm cutting depth at 90° and 30 mm at 45° using a standard 125 mm blade — punching well above its class for framing, trimming, and sheet material work
• High-performance 36V brushless motor provides faster, smoother cutting speeds with reduced wear and an extended service life compared to brushed alternatives
• Dual speed selection (2,600 / 5,000 RPM) allows the operator to match cutting speed to the material for optimal results and efficiency
• Silent mode reduces operating noise for improved comfort during extended use and in noise-sensitive environments
• Blower function continuously clears cutting lines of dust and debris, maintaining a clear sightline throughout the cut
• Optimal blade visibility from both sides of the saw ensures high-precision tracking and accurate, repeatable cuts
• Fine-adjustment system enables quick, precise setting of cutting depth and bevel angles up to 45° for consistent results across varying applications
• Fast-stop electric brake halts blade rotation rapidly after trigger release for improved operator safety
• Overload protection and soft start reduce stress on the motor and workpiece, enhancing both safety and longevity
• Robust aluminium die-cast base provides stability and rigidity without adding unnecessary weight
• At just 2 kg (skin only), the compact and lightweight design maximises manoeuvrability and reduces fatigue during prolonged use
• Integrated LED work light improves visibility in shadowed or low-light cutting areas
• Soft grip handle delivers confident control and comfort throughout the cut

Specifications

• Model: C3605W2Z
• Voltage: 36V
• Blade size: 125 mm
• Bore size: 20 mm
• No-load speed: 2,600 / 5,000 RPM
• Max. cutting depth at 90°: 47 mm
• Max. cutting depth at 45°: 30 mm
• Maximum bevel angle: 45°
• Dimensions (L x W x H): 277 x 176 x 236 mm
• Weight: 2 kg (skin only)
