Features

• Next-generation LiFePO4 (Lithium Iron Phosphate) chemistry delivers significantly lighter weight than equivalent lead acid and AGM batteries
• Internal Battery Management System (BMS) ensures uniform cell charging and discharging for maximum performance and longevity
• BMS provides short circuit, over-current and reverse polarity protection, plus discharge limiting and cut-off voltage management to protect internal cells
• Safer than unprotected lead acid batteries, which can discharge rapidly under short circuit conditions causing fire and damage
• Robust 32650 LiFePO4 internal cells rated for 6,000 cycles at greater than 80% capacity retention
• 10+ year service life expectancy
• Ideal for high-capacity portable power applications and direct replacement of similar-capacity lead acid or AGM batteries
• M5 bolt-down output terminals for a secure, low-resistance connection

Specifications

• SKU: SB2213
• Nominal Voltage: 12.8V
• Capacity: 25Ah (20Hr)
• Watt Hour Rating: 320 Wh
• Continuous Discharge Current: 25A
• Max Continuous Current: 50A (5 sec max)
• Peak Discharge Current: 30A
• Peak Discharge Duration: 5 seconds
• Cut-Off Voltage: ~10V
• Charge Type: Constant Current / Constant Voltage
• Internal Cells: 32650 LiFePO4
• Internal Resistance: 60 mΩ (max 85 mΩ)
• Output Terminals: M5 Bolt Down
• Operating Temperature: 0°C to 45°C (60°C max discharging)
• Storage Temperature: 0°C to 40°C (15°C to 25°C recommended)
• Operating Humidity: RH < 85%
• Storage Humidity: RH < 50%
• Weight: 3.0 kg
• Dimensions (W x H x D): 175 x 125 x 165 mm
• DG Class: 9 | UN3480 | Pack Group II
• Air Freight: Dangerous goods (not permitted unclassified)
