Pressol Grease Gun Standard Includes Flex Hose 12633
Availability:
In stock
SKU
12633
$49.00
Delivery Availability
Delivery Cost & Shipping Time
Pressol Funnel Set 4 Piece 50-100mm Oil Petrol & Acid Resistant 02360
was
$14.90
Special Price
$7.90
- The device processes fats up to NLGI 2 at 20 °C
- Molded sleeve with tight fit on loose grease or cartridge
- According to DIN 1283
- TÜV-certified
- Pump pistons with high accuracy of fit to the cylinder (no apparent lubrication)
- Performance unchanged after 40,000 work cycles
- Die-cast zinc grease press head Z 410
- Secure grip thanks to strong knurled edges
- Secure handle on the push rod
- Non-slip handle on grease gun lever
- Loose lid with clamping piece allows manual support of spring force in any position to compress loose grease or to press the cuff into damaged cartridges
- Low force required for lubrication due to optimum lever ratios
- Quick venting by half a turn of the grease gun tube
SPECIFICATIONS
- Grease gun connection on the pressure side: M 10 x 1
- Filling volume (cm³): 500
- Filling options: 400 g grease cartridge, DIN 1284, or loose grease
- Diameter grease pump piston (mm): 8
- Actuation grease pump piston HHFP: by means of hand lever
- Flow volume/stroke (cm³): 1.2 at 400 bar back pressure
- Delivery pressure up to (bar): 400
- Burst pressure system (bar): 850
- Burst pressure grease press head (bar): 1200
- Push rod actuation via: L-handle
- Cover plate: loose
- Wall thickness grease press tube (mm): 1
- Lacquering: silver
- Weight (kg): 1.25
- Armoured hose, M 10 x 1 a, 8 x 300 mm (12 656)
- Mouthpiece, 4 BA, M 10 x 1 (12 631)
| MPN | 12633 |
|---|---|
| upc | 4103810126338 |
| Manufacturer | Pressol |
