Features

• ROVER Vehicle compliant and certified with VIN plate attached, making this trailer fully road-registerable for hassle-free on-road fuel transport — registration is the responsibility of the owner
• 1,100 L UV-stabilised polyethylene tank features an internal baffle to significantly reduce liquid surge during transit, improving stability and safety on both sealed and unsealed roads
• Bottom suction with a protection plate safeguards the tank outlet from ground strike damage during off-road and farm use
• Hot-dipped galvanised trailer frame delivers superior corrosion resistance and long-term structural durability in harsh agricultural and worksite environments
• Heavy-duty leaf spring suspension with 5-stud Ford wheels and 235/15 All Terrain tyres handles demanding terrain with confidence
• ADR-approved mechanical overrun disc brakes provide compliant, reliable stopping performance when towing at capacity
• Italian Piusi 50 L/min pump secured within a lockable UV-stabilised Australian-made poly storage box, protecting the pump from weather, dust, and theft
• Auto shut-off trigger with swivel prevents overfilling and fuel spillage during refuelling operations
• Heavy-duty Italian Piusi retractable spring-rewind hose reel with simple hose guide and protected latch mechanism reduces hose wear, prevents injury, and speeds up refuelling
• 10 m x 1" hose provides generous reach for refuelling vehicles and machinery without repositioning the trailer
• Dual power connection points — 7-pin electrical connector and Anderson plug — allow the pump to be powered from the tow vehicle at the front of the trailer or from the storage box via the supplied auxiliary cable
• Full LED lighting suite including tail lights, indicators, and registration plate light for safe road use
• Adjustable jockey wheel and 50 mm tow hitch for straightforward coupling and uncoupling

Specifications

• Tank capacity: 1,100 L
• Tank material: UV-stabilised polyethylene with internal baffle and bottom suction protection plate
• Pump: Italian Piusi, 50 L/min
• Trigger: Auto shut-off with swivel
• Hose reel: Piusi retractable spring-rewind, 10 m x 1" hose
• Trailer finish: Hot-dipped galvanised
• Suspension: Heavy-duty leaf spring
• Wheels: 5-stud Ford pattern
• Tyres: 235/15 AT (All Terrain)
• Tow hitch: 50 mm
• Brakes: ADR-approved mechanical overrun disc brakes
• Lighting: LED tail lights, indicators, and registration plate light
• Electrical: 7-pin connector + Anderson plug with auxiliary cable
• Storage box: Lockable UV-stabilised Australian-made poly
• Compliance: ROVER Vehicle compliant and certified with VIN plate
• Dimensions (H x W x L): 1,530 x 1,820 x 3,800 mm
• Weight: 440 kg
