Features

• Designed for fast and accurate diagnostics, testing batteries and charging/starting systems within a protected, reverse-polarity-safe design
• Tests all 12V automotive lead acid cranking batteries, including ordinary lead acid batteries, AGM flat plate, AGM spiral, sealed lead acid (SLA), gel and EFB batteries
• Built-in printing functionality provides instant hard copy test results, helping you find the problem quickly and accurately
• Tests batteries with a low state of charge, with no need to charge before testing
• Reverse polarity connection protection ensures reverse connection will not damage the tester or affect the vehicle and battery
• Multi-function design covers battery, cranking and charge system testing
• Auto-saves results for easy record keeping

Specifications

• Measurement Range: Cold Cranking Amps (CCA) 100-2000 CCA
• Display: LCD, Backlit, 128 x 64px
• Operating Temperature: 0 to 50°C (32 to 122°F)
• Storage Temperature: -20 to 70°C (-4 to 158°F)
• Powered By: Battery Under Test
• Dimensions: 228mm (L) x 109mm (W) x 58mm (H)
• Cable Length: 1400mm
• Weight: 580g
• Voltage Tolerance: 8-30V DC
