Features

• Self-levelling 5-point laser
• Create right angles, plumb, transfer and align heights at distances of up to 30 M away
• Laser points are very visible, bright and fine for marking the middle of the point exactly
• Five laser points: plumb-line dots upwards and downwards as well as three horizontal points which form two 90 angles
• With the 90 transfer, axes can be aligned and, at the same time, two right angles can be created
• Plumb-line function for transferring the layout from the floor to the ceiling
• Compact, rotatable housing with extendable foot for height adjustment for working directly on U-profiles
• Shock-absorbent Stabila soft grip casing
• Protection class IP 54
• Belt pouch

Specifications

• Laser wavelength: 635 nm
• Self-levelling range +/-: 4.50
• Levelling accuracy +/-: 0.30 mm/m
• Laser beam accuracy (up) +/-: 0.30 mm/m
• Laser beam accuracy (down) +/-: 0.40 mm/m
• 90 angle accuracy +/-: 0.20 mm/m
• Measuring range of visible point: 30 M
• Operating life: 20 H
