The RL-SV2S dual-grade laser from Topcon is built for ultimate durability, designed to be rugged and compact, allowing you to get twice the laser for a great price.

Designed for a wide variety of applications, it can be used for horizontal, sloping and vertical laser applications. Slopes up to ±15% can be used in either the X or Y axis. Turn it on its side and use it for layout and alignment applications.

The RL-SV2S excels in long range operation. Need to shoot elevations up to 400m from your laser? No problem! This instrument has the power and range to cover a 800m (diameter) jobsite.

Efficient power usage, the RL-SV2S has a long battery life. The unit also gives you the option of two forms of power, 120 hours of continuous usage with D cell (4 x) batteries (not included), or 65 hours with the included rechargeable battery pack (RL-SV2S-RB model).

The RL-SV2S is “jobsite tough” and with its IP66 rating, the unit can withstand dust, a sudden shower and even torrential rainfall. Topcon stands behind this reliable and accurate laser with a 5 year warranty.

Features:

• Working Range 800m
• Dual Grade ±15%
• Accuracy ±1.5mm @ 30m
• Dust/Water Rating IP66
• LS-80X Hand Receiver
• Rechargeable NIMH Battery

​
Specifications

• Accuracy H: ±10 arc seconds
• Self-Leveling Range Horizontal ±5°
• Grade: Dual ±15%
• Working Area 800 m (diameter)
• Rotation Speed 300, 600 rpm
• Dust/Water Rating IP66
• Operating Temp. -20ºC to 50ºC
• Operating Time NIMH Rechargable (60 hours)
• LS-80X Hand Receiver (±1mm & 2mm)
• Product Length (mm): 440
• Product Width (mm): 390
• Product Height (mm): 270
