Universal Pumps Electronic Pressure System - 45m Max Head 90L/minMax Flow UP MULTI1100PC

Features

• Description The UP-MULTI1100 is a self-priming jet pump surface mounted pressure system with auto-restart electronic pump control for automatic operation. The pump is characterised by: Fully electronic pump controller for automatic pump starting, stopping and resart after power loss or water loss. Dry run protection to prevent pump damage. 2.2 bar cut in pressure. Corrosion resistant pump components to ensure durability. 240V single phase TEFC motor with built-in auto reset thermal overload to prevent the pump from overheating. Applications: Garden and Rainwater use. Multi storey homes and high pressure applications
• Features Liquid: Liquid Type: Clean Water Clean water temperature range: 2 - 35oC Materials: Pump body: 304 Stainless Steel Impeller, Jet/Venturi, Diffuser: Noryl Glass Reinforced Mechanical seal: Carbon/Ceramic/Nitrile O rings: Nitrile Power Cable: 1.2m Cable H05 3G1.0 Installation: Maximum ambient temperature: 40oC Maximum operating pressure: 6 bar Pipe connections suction/discharge: 1" BSPF / 1" BSPM Dimensions: L495mm x D305mm x H480mm Electrical data: Rated voltage: 220 (-6%) - 240V (+6%) Mains frequency: 50 Hz P2 (shaft power) (kW): 1.1 Current: 8A Capacitor: 16 uF Motor duty: Continuous Motor type: Asynchronous, TEFC Motor protection: In-built thermal overload Ingress protection: IPX4 Insulation class: F Hydraulic Data: Max Head: 45 m Max Flow: 90 l/min Number taps: 8 Weight: 14kg
