Features

• Heavy-duty twin-arm fume extraction unit for welding, grinding, cutting, and gouging operations
• Operates on powerful 415V three-phase power supply for industrial-level performance
• Twin 3-metre extraction arms provide wider reach and reduce the need to move the main unit during use
• Dual cleanable cartridge filters offer extended lifespan and significantly reduced operating costs
• Special spark deflection plate protects filters by redirecting coarse particles and hot sparks to the dust bin
• Manual ‘in situ’ filter cleaning via side access door—no removal required and no operator exposure to fume dust
• Working hour counter, filter fullness indicator, and malfunction warning system for reliable monitoring
• Upward exhaust airflow minimizes disturbance of surrounding dust
• Compact and mobile design enables flexible positioning in busy workspaces
• Durable galvanised steel body with acoustic sponge insulation for quieter operation (74 dBA)
• High extraction capacity up to 3,500 m³/hour supports demanding industrial applications
• Ergonomic design for easy access to functions and maintenance
• Arcrobat arms and durable hoses built for high-temperature resistance and long service life
• 7-Year warranty offer* ensures long-term peace of mind

Specifications

• Power Supply: 415V, Three Phase
• Motor Size: 2.2 kW
• Max Air Flow: 3,500 m³/hour
• Air Flow at Suction Point: 1,600 m³/hour
• Filter Type: Dual cleanable cartridge filters
• Filter Surface Area: 28 m² (2 × 14 m²)
• Filter Cleaning: Manual (via access door using compressed air nozzle)
• Noise Level: 74 dBA
• Sound Insulation: Acoustic sponge
• Body Material: Galvanised steel
• Fan Material: Aluminium
• Arm Length: Twin 3-metre arms
• Dimensions: L720 × W785 × H1480 mm
• Weight: ~130 kg
• Warranty: 7 Years (conditions apply)

Applications

• MIG Welding
• Flux-Core (FCAW) Welding
• TIG Welding
• Plasma Cutting
• Grinding
• Arc Gouging
• For high-fume operations, consider automatic cleaning models such as MA300 AUTO or MA350 AUTO
