Features

• Slow revolution 3-cylinder full cast iron pump
• MEPS Compliant Three Phase Electric Motor 415volt, 5.5KW / 7.5HP
• Unique heavy duty high flow belt guards
• Certified Australian Standards tank. 1 x 1/2 bsp air outlet and 1 x 1/4bsp outlet to allow easy connection to an airline or a permanent system
• The unit also has a tank pressure gauge and automatic start stop switch fitted

Specifications

• Model No: ACB75150E
• Pump: 3090, 90mm Diameter 3 Pistons
• Displacement: 900 L/ min (33 cfm)
• Tank Capacity: 150 Litres
• Maximum Pressure: 115 PSI 8 Bar
• Pump RPM: 780 rpm
• Motor: 7.5hp (5.5kw)Volts/amps: 415v
• Shipping Dimensions: 160kg, 130 x 48 x 98cm
