Features

• Powered by a 6.5HP OHV 4-stroke air-cooled petrol engine with electric key start.
• Delivers an impressive 30-ton splitting force for heavy-duty hardwood applications.
• 2-stage hydraulic pump for faster pressure build-up and improved efficiency.
• Heavy-duty 100mm x 580mm hydraulic cylinder for powerful and consistent performance.
• 7” (178mm) hardened steel wedge for superior splitting strength.
• Fast 17-second cycle time for quick split and return operation.
• Auto return valve automatically retracts ram when lever is released.
• Operates in both horizontal and vertical positions for maximum versatility.
• Handles logs up to 610mm (24”) in length and up to 305mm (12”) in diameter.
• Large 16” pneumatic tyres and jockey wheel for easy manoeuvrability.
• Suitable for towing up to 72 km/h (45 MPH).
• 12V 9AH maintenance-free lead-acid battery included.

Specifications

• Model: LS30JTTESBD
• Engine: 6.5HP, OHV, 4-Stroke, Air Cooled Petrol, Electric Start
• Splitting Force: 30 Tons
• Pump: 2-Stage Hydraulic Pump
• Hydraulic Cylinder: 100mm x 580mm stroke
• Hydraulic Oil Supplied: 10 Litres ISO 46
• Oil Tank Capacity: 12 Litres
• Wedge: 7” (178mm) Hardened Steel
• Cycle Time: 17 Seconds
• Maximum Log Length: 610mm (24”)
• Maximum Log Diameter: 305mm (12”)
• Towing Speed: Maximum 72 km/h (45 MPH)
• Wheels: 16” Pneumatic Tyres
• Battery: 12V, 9AH Maintenance-Free Lead-Acid
• Jockey Wheel Size: 8” x 2” (200mm x 50mm)
• Shipping Dimensions: 187 x 51 x 68 cm
• Shipping Weight: 270 kg
