Features

• Delivers an impressive 40-ton splitting force for heavy-duty firewood processing.
• Engine not included, allowing customisation with a user-supplied compatible engine.
• Heavy-duty 127mm x 493mm hydraulic cylinder for powerful and consistent performance.
• 200mm wearproof cast steel wedge for maximum durability and splitting efficiency.
• 2-stage gear pump providing a fast 16-second cycle time.
• Auto return valve with safe relief function for enhanced operational safety.
• Handles logs up to 550mm in length and 300mm in diameter.
• Operates in both horizontal and vertical positions for versatile log handling.
• Heavy-duty log table for easier loading and unloading.
• 406mm DOT pneumatic wheels and 203mm jockey wheel for smooth towing on private property.
• Includes safety chain, wheel fenders, and reflectors for safer transport.
• Maximum towing speed of 116 kph (private property use only).
• Supplied with 20 Litres OSO46 hydraulic oil.

Specifications

• Model: LS40WEBD
• Maximum Splitting Force: 40 Ton
• Cylinder Size: 127mm x 493mm
• Wedge Height: 200mm (Heavy-Duty Cast Steel)
• Maximum Log Length: 550mm
• Maximum Log Diameter: 300mm
• Pump: 2-Stage Gear Pump
• Cycle Time: 16 Seconds
• Hydraulic Oil Supplied: 20 Litres OSO46
• Towing Wheels: 406mm DOT Pneumatic
• Jockey Wheel: 203mm x 51mm
• Maximum Towing Speed: 116 kph
• Engine: Not Included
• Packing Dimensions: 1720 x 520 x 790 mm
• Packaged Weight: 300 kg
