Features

• Measures up to 2000A AC/DC and 1000V AC/DC with high accuracy using TRMS technology
• Rugged industrial-grade design withstands 6.6-foot (2 m) drop for jobsite durability
• Low-Impedance (LoZ) mode detects and eliminates ghost or stray voltages
• Dedicated inrush current capture mode for measuring startup current surges
• Integrated non-contact voltage tester built into the clamp
• Test leads support measurements of voltage, resistance, continuity, frequency, duty-cycle, capacitance, and diode testing
• Back-lit display provides clear readings in low-light environments
• Features include audible continuity, min/max recording, data hold, and auto shut-off after 30 minutes
• Safety rated to CAT IV 600V and CAT III 1000V standards with Class 2 double insulation
• Low-battery indicator and easily accessible battery compartment
• Compatible with optional Magnetic Hanger (Cat. No. 69417 – sold separately)

Specifications

• Type: Clamp Meter
• Application: Measures current up to 2,000 A AC/DC
• Special Features: LoZ mode, inrush current capture, integrated NCV tester
• Material: Plastic/Electronics
• Batteries: 2 x AAA
• Auto Shut Off: Yes
• Jaw Size: 2" (5 cm)
• Drop Protection: 6.6' (2 m)
• Display: 6,000-count LCD
• Functions: Audible continuity, capacitance, diode test, frequency, duty cycle, min/max, data hold, LoZ, inrush current
• Voltage Range: 1000 V AC/DC
• Frequency Range: Up to 500 kHz
• Current Range: 2,000 A AC/DC
• Capacitance: 6000 µF
• Resistance (Ohms): 60 MΩ
• DC Polarity Indicator: Yes
• Ingress Protection: IP40
• Standard: CAT IV 600V, CAT III 1000V
• Overall Dimensions: 10.39" (26.4 cm) L x 1.70" (4.3 cm) H x 3.90" (9.9 cm) W
• Weight: 17.6 oz (499 g)
• UPC: 092644692352

Includes

• Clamp Meter
• Carrying case
• Instruction manual
• Straight input test leads
• Batteries
