Features

• True RMS clamp meter delivers accurate and reliable measurements across a wide range of applications
• Measures AC/DC voltage, AC/DC current, resistance, diode test, continuity, capacitance and frequency/duty cycle
• Transflective reverse-contrast display provides excellent visibility in both sunlight and dark environments
• Lighted dial ensures clear visibility and easy reading, even in low-light environments
• Low Impedance (LoZ) mode identifies and eliminates ghost voltages, preventing false readings and ensuring more accurate results
• Non-contact voltage (NCV) detection built into the clamp jaw, with escalating audible and visual alerts as the clamp nears the voltage source
• Durable construction rated IP40 for ingress protection and withstands drops up to 2m (6.6')
• Ergonomic design with overmold provides a comfortable grip, with easy thumb dial adjustment
• Side-mounted test lead holder and back mount accommodate an optional magnetic hanger (Cat. Nos. 69445 or 69417) for hands-free operation
• Auto-ranging with auto-power off for convenient, reliable operation

Specifications

• Type: Pro Clamp Meter
• Application: Variety of Electrical Diagnostic and Troubleshooting Applications
• Special Features: Transflective Reverse-Contrast Display, Lighted Dial, Built-in Lead Holder
• Material: ABS/Electronics
• Batteries: 3 x AAA
• Auto-Power Off: Yes
• Jaw Size: 3.6cm (1.4")
• Drop Protection: 2m (6.6')
• Display: Transflective Reverse-Contrast with 6000 Count LCD
• Functions: AC/DC Voltage, AC/DC Current, Resistance, Audible Continuity, Low Impedance, Non-Contact Voltage Testing, Diode Test, Capacitance, Frequency/Duty Cycle, Min/Max Value, Rel/Zero, Data Hold
• Auto Ranging: Yes
• TRMS: Yes
• Voltage: 1000V AC, 1000V DC
• Frequency: 10Hz - 60kHz
• Current: 600A
• Capacitance: 6000µF
• Ohms (Resistance): 60MΩ
• DC Polarity Indicator: Yes
• Ingress Protection: IP40
• Standard: CAT IV 600V, CAT III 1000V, Class 2, Double Insulation, CE, UKCA
• Overall Length: 23cm (9.06")
• Overall Height: 4.2cm (1.65")
• Overall Width: 8.8cm (3.47")
• UPC: 092644694493

Includes

• 1 x Clamp Meter
• 1 x Right-Angle Input Test Leads
• 1 x Storage Pouch
• 1 x Instruction Manual
• 3 x AAA Batteries
