Features

• Traces and locates cables on active networks when used with the Digital Tracing Probe (VDV500-223, sold separately)
• Wire mapping capabilities with shield detection for pin-to-pin verification (requires VDV500-223)
• Rugged Angled Bed of Nails (ABN) clips ensure secure wire attachment
• RJ45 port supports testing of RJ45, RJ11, and RJ12 data cables
• Tests for continuity and polarity with clearly labeled LED indicators
• Three selectable tone cadences for flexible signal identification
• Features Auto Power-Off and Low Battery Indicator for energy efficiency

Specifications

• Type: Digital Wire Tracing
• Application: Wire Toning
• Special Features: Performs Analogue and Digital Toning
• Material: ABS
• Batteries: 4 x AAA
• Battery Life: 20 hrs
• Low Battery Indicator: Yes
• Power-On LED Indicator: Yes
• Auto Power-Off: Yes
• Adjustable Volume: No
• Amplifier Overload Indication: No
• Continuity Testing: Yes
• Tones: 3
• Visual Notification: LED
• Replaceable Tip: No
• Self-Storing Remote: No
• Included: Tone Generator; 4 x AAA Batteries
• Overall Length: 2.2'' (5.6 cm)
• Overall Height: 4.7'' (11.9 cm)
• Overall Width: 1.1'' (2.8 cm)
• Weight: 5.3 oz (150 g)
• UPC: 092644583896
