Features

• Automatically ranging TRMS HVAC clamp meter for precise, reliable readings
• Measures 600A AC current and inrush current via clamp
• Test leads measure 750V AC/600V DC, DC microamps, resistance, continuity, frequency, duty-cycle, capacitance, and diodes
• Built-in K-type thermocouple port supports wide temperature measurement range from -148°F to 1832°F (-100°C to 1000°C)
• Integrated non-contact voltage tester (NCVT) in clamp jaw for detecting AC current
• Backlit LCD with dual voltage and current (V + A) display for simultaneous readings
• Dedicated modes for DC microamp and inrush current capture
• Built-in work light for visibility in low-light environments
• Durable housing withstands drops from up to 6.6 feet (2 m)
• Safety rated: CAT IV 600V, CAT III 750V, Class 2, double insulation
• Compatible with optional Magnetic Hanger (Cat. No. 69417 – sold separately)

Specifications

• Type: HVAC TRMS Clamp Meter
• Application: Measures AC current, inrush current, AC/DC voltage, DC microamps, resistance, continuity, frequency, capacitance, temperature, diodes
• Special Features: TRMS, NCVT, dual V + A display, built-in worklight
• Material: ABS/Electronics
• Batteries: 3 x AAA
• Auto Power-Off: Yes
• Jaw Size: 1.25" (3.2 cm)
• Drop Protection: 6.6' (2 m)
• Display: 6000-count LCD
• Functions: TRMS, AC current, inrush current, AC/DC voltage, DC microamps, resistance, continuity, frequency, duty-cycle, capacitance, temperature, NCVT, diode test, min/max, data hold
• Voltage Range: 750 V AC / 600 V DC
• Frequency Range: 60 kHz
• Current Range: 600 A
• Capacitance: 6.000 mF
• Resistance (Ohms): 60 MΩ
• DC Polarity Indicator: Yes
• DC Microamp: 600 µA
• Temperature Range: -148°F to 1832°F (-100°C to 1000°C)
• Accuracy: See instructions
• Standard: CAT IV 600V, CAT III 750V, Class 2, Double Insulation
• Overall Dimensions: 9.24" (23.5 cm) L x 1.59" (4 cm) H x 3.77" (9.6 cm) W
• Weight: 12.5 oz (355 g)
• UPC: 092644693786

Includes

• Clamp Meter
• Right-angle input test leads
• Push-on alligator clips
• K-type thermocouple
• Storage pouch
• Instruction manual
• 3 x AAA batteries
