Features

• 13HP air-cooled, 4-stroke single-cylinder petrol engine with vertical shaft and electric start
• Standard 25.4mm (1") vertical shaft suitable for ride-on mowers and other vertical-shaft machines
• Overhead valve (OHV) design ensures lower operating temperatures, improved fuel efficiency, and extended engine life
• Onboard low oil alert system automatically shuts down the engine to prevent damage
• Lightweight and compact design for easy installation and versatile applications
• Reliable and durable construction for consistent performance in demanding applications
• Max power output: 13HP @ 3600 RPM, Max torque: 20.5 Nm @ 2500 RPM, Compression ratio: 9:1

Specifications

• Brand: Millers Falls
• Model: QPVS13ES
• Engine Type: Air-cooled, 4-stroke, single-cylinder petrol
• Displacement: 340cc
• Bore & Stroke: 88 x 56mm
• Maximum Power Output: 13HP @ 3600 RPM
• Maximum Torque: 20.5 Nm @ 2500 RPM
• Compression Ratio: 9:1
• Start Mode: Electric start (12V battery connection)
• Shaft Diameter: 25.4mm (1")
• Shaft Length: 80mm
• Overall Dimensions: 415mm (L) x 442mm (W) x 315mm (H)
• Package Dimensions: 48cm x 46cm x 45cm (excluding shaft)
• Package Weight: 32kg
