Features

• Creates a fine, level seedbed in a single pass—ideal for soil preparation in rocky conditions
• Effectively removes and buries stones, bricks, and grass up to 165 cm wide and 120 mm deep
• Sturdy cast-iron gearbox for heavy-duty performance and durability
• Equipped with hardened blades for long wear life in tough soil conditions
• Reverse-rotating tilling shaft for efficient soil pulverisation and debris separation
• Automatic chain tensioner for reduced maintenance and consistent operation
• Adjustable rear net roller and cage roller for soil levelling and compaction
• Universal Cat I and II three-point hitch with EC safety guards for secure tractor attachment
• Ideal for use in agriculture, parks, gardens, sports fields, greenhouses, and golf courses
• Supplied complete with PTO shaft and safety slip clutch

Specifications

• Model: FISB165A
• Working width: 1550 mm
• Working depth: 120 mm
• PTO speed: 540 r/min
• Rotor speed: 220 rpm
• Tractor power requirement: 35–65 HP
• Working efficiency: 2400–3200 ㎡/h
• PTO spline: 6 x 8 x 700 mm
• Rotor flanges: 8
• Blades per flange: 4 (2 on each end flange)
• Total blades: 28
• Dimensions: 1760 x 1330 x 920 mm
• Weight: 410 kg
