Features

• Heavy-duty reverse-till design for efficient seedbed preparation with fewer passes
• Gear-driven system delivers powerful, reliable performance in hard or virgin soil
• 48 replaceable, curved tynes made from 6 mm thick and 80 mm wide hardened steel
• Eight flanges with six tynes per flange and three cutters on each end for full soil coverage
• Four adjustable depth settings with a maximum tilling depth of 160 mm
• Heavy-duty cast iron central gearbox with slip clutch for gearbox and PTO protection
• Adjustable skid shoes and rear deflector for controlled finish and debris containment
• Heavy-duty drag board with zinc-plated springs for smooth, leveled soil output
• Rotor swing diameter of 475 mm enables deep and effective tilling
• Laser-cut steel plates with tab and weld design for manufacturing accuracy and durability
• Supplied complete with PTO drive shaft and safety slip clutch
• Suitable for 40–65 HP tractors with CAT 1 three-point linkage
• Durable powder-coated finish for resistance to corrosion and wear

Specifications

• Model: FIRTLGM180
• Working width: 1750 mm
• Tilling depth: 100–160 mm
• Tilling width: 180 mm
• Number of tynes: 48
• Number of flanges: 8
• PTO speed: 540 r/min
• Rotor shaft speed: 243 rpm at 540 rpm
• Rotor swing diameter: 475 mm
• Assembled dimensions: 2060 x 925 x 1020 mm
• Shipping dimensions: 2000 x 810 x 770 mm
• Weight: 405 kg
