Features

• Heavy-duty reverse-till design for efficient and deep soil cultivation with fewer passes
• Durable gear-driven system ensures reliable performance in tough soil conditions
• 54 curved, replaceable tynes made from 6 mm thick and 80 mm wide hardened steel
• Nine flanges with six tynes per flange and three cutters on each end for thorough coverage
• Four adjustable depth settings with a maximum tilling depth of 160 mm
• Heavy-duty cast iron central gearbox paired with an 80HP PTO slip clutch for protection
• Adjustable skid shoes for depth control and a clean tilling result
• Rear deflector keeps soil and debris beneath the tiller for optimal pulverisation
• Heavy-duty drag board with zinc-plated springs for smooth and even finish
• Laser-cut steel with tab and weld construction for accuracy and strength
• Rotor swing diameter of 475 mm for deep and effective tilling
• Supplied with PTO drive shaft and safety slip clutch
• Designed for 65–80 HP tractors with CAT 1 three-point linkage
• Durable powder-coated finish resists corrosion and wear

Specifications

• Model: FIRTLGM200
• Working width: 1950 mm
• Tilling depth: 100–160 mm
• Tilling width: 180 mm
• Number of tynes: 54
• Number of flanges: 9
• PTO speed: 540 r/min
• Rotor shaft speed: 243 rpm at 540 rpm
• Rotor swing diameter: 475 mm
• Assembled dimensions: 2280 x 925 x 1020 mm
• Shipping dimensions: 2220 x 810 x 770 mm
• Weight: 505 kg
