Features

• Delivers a powerful 30-ton splitting force for demanding hardwood applications.
• No engine supplied, allowing flexibility to fit a user-provided engine.
• Heavy-duty 115mm x 575mm hydraulic cylinder for strong and consistent performance.
• 14 GPM 2-stage gear pump for fast and efficient pressure build-up.
• 8” (200mm) wear-proof hardened cast steel splitting wedge for superior durability.
• Splits logs up to 610mm (24”) in length and 305mm (12”) in diameter.
• Operates in both horizontal and vertical positions for versatile log handling.
• Auto return valve retracts ram automatically for faster cycle times.
• Hydraulic lifting table included for easier log loading and reduced strain.
• 16” x 6.5” pneumatic D.O.T wheels for smooth mobility across terrain.
• Manufactured by Black Diamond for reliable, high-performance wood splitting.

Specifications

• Model: LS30WEJTTBD
• Maximum Splitting Force: 30 Ton
• Cylinder Size: 115mm x 575mm (4-1/2” x 23”)
• Hydraulic Pump: 14 GPM, 2-Stage Gear Pump
• Splitting Wedge Height: 8” (200mm)
• Hydraulic Oil Supplied: 10 Litres ISO 46
• Oil Tank Capacity: 12 Litres
• Maximum Log Length: 610mm (24”)
• Maximum Log Diameter: 305mm (12”)
• Operating Positions: Horizontal and Vertical
• Lift Table: Included
• Pneumatic Wheels: 16” x 6.5”
• Engine: Not Included
• Shipping Dimensions: 187 x 51 x 68 cm
• Shipping Weight: 257 kg
