Features

• Powered by a 15HP manual start petrol engine for heavy-duty performance.
• Massive 45-ton splitting force for demanding commercial and large-scale firewood tasks.
• Heavy-duty 20cm high cast steel wedge for superior durability and splitting efficiency.
• Fast 2-stage gear pump delivering a minimum 18-second split and return cycle.
• Operates in both horizontal and vertical positions for versatile log handling.
• Auto return valve with safe relief function for smooth and secure operation.
• Handles logs up to 55cm in length and up to 305mm (12”) in diameter.
• 16” DOT pneumatic tyres for stable towing on private property.
• 8” x 2” jockey wheel for easy manoeuvrability and positioning.
• Maximum towing speed of 72 km/h (private property use only).
• Supplied with 20 Litres OSO46 hydraulic oil.

Specifications

• Model: LS45BD
• Engine: 15HP, Manual Start, Petrol
• Maximum Splitting Force: 45 Ton
• Cylinder Size: 5” x 19.4” Heavy-Duty Hydraulic Cylinder
• Pump: 2-Stage Gear Pump
• Cycle Time: Minimum 18 Seconds
• Hydraulic Oil Supplied: 20 Litres OSO46
• Wedge Height: 20 cm (Cast Steel, Wearproof)
• Maximum Log Length: 55 cm
• Maximum Log Diameter: 305 mm (12”)
• Working Positions: Horizontal and Vertical
• Wheels: 16” DOT Pneumatic Tyres
• Jockey Wheel: 8” x 2” (200mm x 50mm)
• Maximum Towing Speed: 72 km/h (Private Property Use Only)
• Package Dimensions: 172 x 52 x 79 cm
• Package Weight: 315 kg
• Shipping Weight: 320 kg
