Features

• Robust circular saw can be used directly on guide rails from
• Metabo and other manufacturers for precise, long cuts
• Fast, precise cross cuts thanks to easy coupling with a
• Metabo cross cutting rail Light guide plate made from die cast aluminium
• Grip area with non-slip soft-grip surface
• Clearly visible cutting indicator for precise sawing after initial cut 0 degrees position re-adjustable for highest cutting precision
• Extraction possibility by means of connecting an all-purpose vacuum cleaner
• Controllable chip ejection by means of rotating extraction nozzle
• Precision guide rail available as accessory

Specifications

• Rated Input Power: 1500W
• Output Power: 840W
• Maximum Cutting Depth At 90 : 66mm (2-5/8")
• Maximum Cutting Depth At 45 : 47mm (1-7/8")
• Maximum Cutting Depth With Guide Rail: 61mm (2-13/32")
• Saw Blade Diameter: 190mm (7-1/2")
• Bore: 30mm (1-3/16")
• No-Load Speed: 5000rpm
• Revolutions At Rated Load: 3800rpm
• Maximum Cutting Speed: 50m/s
• Cable Length: 4m
• Noise Emision: Sound Pressure: 95dB(A) Sound Power Level (LwA): 106dB(A)
• Sound Pressure: 95dB(A)
• Sound Power Level (LwA): 106dB(A)
• Weight: 4.9kg
