Features

• Powered by a 7hp 4-stroke OHV engine for reliable and efficient operation
• Delivers an impressive flow rate of 1100 litres per minute
• Rugged steel frame protection for enhanced durability
• Cast iron volute and impeller with a silicon carbide seal for long-lasting performance
• Capable of handling solids up to 5/8", making it ideal for moving dirty water
• T-handles for tool-less access, allowing rapid cleaning of the pump body
• Separated shock pads on the support base minimize vibrations and improve stability

Specifications

• Bore x Stroke: 70 x 55mm
• Displacement: 212ml
• Compression Ratio: 9:1
• Net Power: 4.4kW / 3600rpm
• Fuel Consumption: ≤395 g/kW-h
• Net Torque: 12N.m / 2500rpm
• Pump Set: 3" semi-trash pump
• Suction Port Diameter: 75mm (3")
• Discharge Port Diameter: 75mm (3")
• Suction Head Lift: 7m
• Total Head Lift: 26m
• Discharge Capacity: 66m³/h (1100 litres per minute)
• Dimensions (L x W x H): 552 x 432 x 450mm
• Net Weight: 35kg
