Features

• Economic, efficient automatic changeover valve enabling stored rainwater use in toilets, laundry and garden applications
• Smoothly diverts to mains water supply when the rainwater storage tank runs empty
• Ideal for domestic and commercial applications with pumps fitted with an auto-restart pressure controller
• Automatic switchover from rainwater storage tank to mains
• Hydraulic design with no electrical components for increased reliability
• Robust low lead brass construction withstands harsh weather
• Meets NCC Lead Free requirements
• Simple installation, connects to the Waterboy 3kW controller for use with 40L and 60L Jet Pumps
• Suitable as a retrofit or upgrade option for other changeover devices
• Integrated pressure limiting valve rated at 200 kPa
• WaterMark Approved for use with potable water (WMTS 477:2016, LN: 021636)
• 5 year replacement warranty

Specifications

• Brand: Waterboy
• Application: Automatically switches between rainwater and mains water when connected to a compatible jet pump and controller
• Water type: Clean
• Weight: 2.2 kg
• Width: 162 mm
• Height: 56 mm
• Depth: 157 mm
• Maximum mains pressure: 1000 kPa
• Minimum pump pressure: 200 kPa
• Recommended pump cut-in pressure: 200 kPa
• Nominal flow rate: 50 L/min
• Maximum water temperature: 40°C
• Minimum water temperature: greater than 1°C (protect from freezing)
• Compatible with part numbers: 7575101, 7575100, 7575127
• Pumping capacity: 40L, 50L, 60L
• Inlet connection: 3/4" mains water inlet, 1" rainwater inlet (G thread)
• Outlet connection: 3/4" (G thread)
• Fuel type: Water
• Warranty: 5 year replacement warranty
