Features

• Premium Italian-made construction ensures exceptional quality, durability, and precision for demanding professional cutting applications.
• Based on the NEW350EDV model with the addition of a pneumatic vice for enhanced productivity and ease of use.
• Swivel head pivots 45° to both left and right, offering outstanding versatility for miter and angled cuts.
• User-friendly trigger switch operation provides smooth, controlled cutting for improved accuracy and operator comfort.
• Quick-locking double vice with sliding counter vice securely holds materials, delivering clean, burr-free cuts every time.
• Two-speed machine: 20 rpm setting for stainless steel and 40 rpm for mild steel, optimizing performance for different materials and applications.
• Pneumatic vice automatically closes when triggered from foot control, allowing hands-free clamping and enhancing operator safety and efficiency.
• Advanced recirculating coolant system with electric pump ensures instant, flood-applied coolant for cooler cuts, improved surface finish, and extended blade life.
• Adjustable material stop enables consistent, repeatable cuts, making it ideal for repetitive production work.
• Equipped with a safety emergency stop switch for immediate shutdown, ensuring maximum operator safety.
• Includes a 12-month warranty for peace of mind and reliable support.
• Supplied complete with blade, ready for immediate use out of the box.
• Stand shown is available separately (Part# MC-STAND315) for added convenience and workspace flexibility.

Specifications

• Motor: 3.2 hp, three-phase (415V)
• Blade speed: Two speeds, 20 / 40 rpm
• Blade size: 350 mm
• Blade bore: 32 mm
• Weight: 210 kg

Cutting Capacity

• 90° cutting capacity — Solid round: 60 mm; Round tube: 110 mm; Square: 100 mm; Rectangle: 120 x 80 mm
• 45° cutting capacity (left & right) — Solid round: 55 mm; Round tube: 80 mm; Square: 80 mm; Rectangle: 80 x 80 mm
