Features

• Premium Italian-made construction ensures exceptional quality, precision, and durability — perfect for demanding industrial applications.
• Dual column design provides faster cutting of solid materials and improved finish quality, enhancing overall performance.
• Equipped with dual vertical vices for efficient bundle cutting and maximum stability during operations.
• Fully automatic CNC-controlled machine for advanced automation and high-volume productivity.
• 10" touch screen control panel offers intuitive, user-friendly operation and easy programming.
• Supports 39 programs, each with up to 50 steps and integrated piece counter, ideal for precise batch cutting.
• Digital control of cut quality and length ensures consistent, high-precision results.
• Hydraulic material feeder with 600 mm stroke and no length limitation, perfect for continuous and long cuts.
• Fully guarded design enhances operator safety and minimizes risk during operation.
• Swivel head enables mitre cuts from 0° to 60°, providing excellent versatility for angled and compound cuts.
• Integrated recirculating coolant system keeps the blade cool, improves cut finish, and extends blade life.
• Equipped with a safety emergency stop switch for immediate shutdown to ensure maximum operator safety.
• Delivered complete with a sturdy stand and high-quality blade, ready for immediate use out of the box.
• Optional software available to create a series of cutting profiles from a computer for use with the Special 391AV MAX model.

Specifications

• Motor: 2.15 hp, Three Phase (415V)
• Blade speed: Variable from 20 to 90 m/min
• Blade size: 27 mm x 0.9 mm x 3200 mm
• Weight: 960 kg

Cutting Capacity

• 90° cutting capacity — Solid Round: 230 mm; Round: 300 mm; Square: 290 mm; Rectangle: 320 x 290 mm
• 45° right cutting capacity — Solid Round: 200 mm; Round: 230 mm; Square: 230 mm; Rectangle: 230 x 230 mm
• 60° right cutting capacity — Solid Round: 130 mm; Round: 130 mm; Square: 125 mm; Rectangle: 130 x 125 mm
