Features

• Premium Italian-made construction ensures exceptional quality, precision, and durability for demanding industrial applications.
• Swivel head pivots 45° to both left and right, offering excellent versatility for miter and angled cuts.
• Semi-automatic operation streamlines the cutting cycle with these automated steps:
  • Vice closes and blade motor starts.
  • Cutting head performs downstroke.
  • Head returns to the start position and blade motor stops.
  • Vice re-opens automatically.
• Quick-locking double vice securely holds materials, ensuring precise, burr-free cuts every time.
• Two-speed machine: 20 rpm for cutting stainless steel and 40 rpm for mild steel, optimizing performance for various materials.
• Integrated recirculating mechanical coolant system supplies coolant to both sides of the blade, extending blade life and improving surface finish.
• Powered hydraulic down feed and return enhance cutting efficiency and operator safety.
• Requires a compressor to power the vice system for reliable clamping performance.
• Adjustable material stop ensures consistent, repeatable cuts, ideal for production and repetitive tasks.
• Includes a 12-month warranty for peace of mind and dependable support.
• Supplied complete with blade and stand, ready for immediate use.
• Optional remote foot switch and emergency stop switch available separately (Part# MCP-NEW350S-090) for added convenience and safety.

Specifications

• Motor: 3.2 hp, three-phase (415V)
• Blade speed: Two speeds, 20 / 40 rpm
• Blade size: 350 mm
• Blade bore: 32 mm
• Weight: 280 kg

Cutting Capacity

• 90° cutting capacity — Solid round: 60 mm; Round tube: 110 mm; Square: 100 mm; Rectangle: 120 x 80 mm
• 45° cutting capacity (left & right) — Solid round: 55 mm; Round tube: 80 mm; Square: 80 mm; Rectangle: 80 x 80 mm
