Features

• Premium Italian-made quality with an extra heavy-duty design ensures exceptional durability, strength, and reliable performance for industrial cutting tasks.
• Compound mitre saw engineered specifically for non-ferrous metals such as aluminium, copper, and brass, delivering clean, precise cuts every time.
• Swivel head pivots 45° to both right and left, providing excellent versatility for a wide range of angled and miter cuts.
• Mitre head adjustable 45° to the left for advanced cutting flexibility.
• Easy-to-use trigger switch operation allows for smooth, controlled cutting and precise results.
• Twin manual sliding vices with Teflon jaws securely clamp materials without marking, ensuring burr-free, high-quality finishes.
• Fully recirculating coolant system helps maintain cooler cutting temperatures, extends blade life, and improves surface finish quality.
• Includes sturdy stand for enhanced stability and convenient working height.
• Upgraded pneumatic features:
  • Two pneumatic spring return vices automatically clamp material when the trigger switch is pulled.
  • Cutting fluid supply to the blade is activated simultaneously for optimal cooling and lubrication.
  • Material is automatically released, and fluid mist deactivates upon head return, streamlining operation.
• Equipped with a safety emergency stop switch for immediate shutdown, enhancing operator safety.
• Includes a 12-month warranty for peace of mind and dependable support.
• Blade sold separately, allowing you to choose the best blade for your specific cutting needs.
• Requires a compressor to operate the pneumatic vice system.

Specifications

• Motor: 3 hp, three-phase (415V)
• Blade speed: Single speed, 3,000 rpm
• Blade size: 400 mm
• Blade bore: 32 mm
• Weight: 190 kg

Cutting Capacity

• 90° cutting capacity — Solid round: 60 mm; Round tube: 140 mm; Square: 110 mm; Rectangle: 180 x 100 mm
• 45° cutting capacity (left & right) — Solid round: 60 mm; Round tube: 130 mm; Square: 100 mm; Rectangle: 150 x 100 mm
